Introduction
The 20W Two-Way Woofer Amplifier TDA2005 is a powerful yet compact amplifier that enables a high-quality audio output for any audio system. This versatile amplifier can be easily integrated into a car audio system, home theater, or even a portable audio player. It’s designed to provide excellent sound quality with minimal distortion, and its small size allows it to be mounted in tight spaces.
Circuit Diagram
of 20W Two-Way Woofer Amplifier
This amplifier can be designed using a few basic components. The circuit diagram of this project is shown below.
More Circuit Layouts









Features of 20W Two-Way Woofer Amplifier
The TDA2005 is a dual-channel amplifier that can deliver up to 20 watts per channel at 4 ohms. It can operate with a wide range of supply voltages, making it suitable for use in various applications. The amplifier also comes with several protection features such as thermal shutdown, overload protection, and short circuit protection, ensuring its durability and reliability.
Moreover, the TDA2005 is designed to be compatible with a wide range of speakers, including subwoofers, making it an ideal solution for audio enthusiasts who want to produce high-quality sound. The amplifier is also easy to install, and its compact size allows it to fit into tight spaces, making it ideal for use in a car audio system.
High output power:
Pout = 10W + 10W @ RL = 2 ohm, THD=10%
Pout = 20W @ RL = 4 ohm, THD=1%
Conclusion of 20W Two-Way Woofer Amplifier
The TDA2005 is an excellent amplifier that provides excellent sound quality, durability, and versatility. Its powerful yet compact design makes it an ideal solution for any audio system, and it’s easy to install, making it perfect for beginners and experts alike. If you’re looking for an amplifier that can deliver high-quality sound, the 20W Woofer Amplifier TDA2005 is definitely worth considering.
