TIP2955 PNP Power Transistor Pinout Datasheet

Introduction

The TIP2955 is a PNP silicon power transistor designed for high-current and medium-voltage applications. Packaged in the TO-247 case, this device offers superior thermal conductivity, mechanical strength, and power handling capabilities compared to older TO-218 or TO-3P packages. It is commonly used in linear power amplifiers, regulated power supplies, UPS systems, and motor drivers, where reliability and efficiency are critical.

TIP2955 PNP Power Transistor Datasheet
TIP2955 PNP Power Transistor Datasheet



With a collector-emitter voltage (Vce) rating of 60V and a collector current of up to 15A, the TIP2955 is well-suited for driving large loads. Its power dissipation rating of 90W allows it to handle significant energy while maintaining safe operation when used with a proper heatsink. The transistor exhibits a DC gain (hFE) range between 20 and 70, which makes it ideal for both switching and linear amplifier applications.

TIP2955 PNP Power Transistor

TIP2955 PNP Power Transistor
TIP2955 PNP Power Transistor




The TIP2955 is often paired with its complementary NPN counterpart, the TIP3055, to form a robust push-pull amplifier stage. This combination is widely used in Class AB audio amplifiers, ensuring low distortion, efficient current drive, and stable operation. Its versatility and availability make the TIP2955 a staple in both consumer electronics and industrial electronics projects.

TIP2955 Pinout

TIP2955 PNP Power Transistor Pinout
TIP2955 PNP Power Transistor Pinout



TIP2955 Transistor Key Features

  • High current handling capability (up to 15A).
  • Strong PNP power transistor in TO-247 package.
  • Excellent thermal performance and rugged design.
  • Suitable for linear amplifier and switching operations.
  • Complementary to TIP3055 NPN transistor.

Specifications/Characteristics of TIP2955 PNP Transistor

  • Transistor Type: PNP
  • Collector-Emitter Voltage (Vce): 60V
  • Collector-Base Voltage (Vcb): 100V
  • Emitter-Base Voltage (Veb): 7V
  • Collector Current (Ic): 15A max
  • DC Current Gain (hFE): 20 – 70
  • Power Dissipation (Ptot): 90W (with heatsink)
  • Package Type: TO-247



TIP2955 Pin Configuration

Pin#Pin NamePin Description
1
Base (B)
Provides input control for transistor conduction
2
Collector (C)
Main terminal for current flow
3
Emitter (E)
Connected to the load or supply rail
TIP2955 Specifications Table

More Circuit Layouts




Key Applications of TIP2955 PNP Power Transistor

  • Audio amplifier output stages (Class AB designs)
  • DC motor control circuits
  • Inverters and UPS systems
  • Voltage regulators and power supplies
  • Battery charging circuits
  • General-purpose high-current switching



NPN Complimentary Transistor

TIP3055 (NPN Power Transistor, TO-247) is the NPN complementary transistor of TIP2955.

Equivalent Transistors of TIP2955

  • MJ2955 (PNP power transistor, TO-3 package)
  • BD250C (PNP alternative)
  • TIP36C (high-voltage PNP transistor)
  • MJ15016 (PNP high-power transistor)
  • 2N2955 (classic PNP transistor, TO-3 Package)

(Pin configuration of some transistors mentioned above may different from TIP2955).

Datasheet of TIP2955 NPN Power Transistor

Click the following Button below to download the datasheet of TIP2955 Transistor :
