BC327 PNP Transistor Pinout Datasheet

Introduction

The BC327 transistor is a PNP bipolar junction transistor (BJT) designed for low to medium power switching and amplification. With its ability to handle a collector current up to -800mA, it is suitable for driving loads such as relays, LEDs, and small motors, making it a preferred choice for a variety of switching applications. Its moderate power handling capacity, along with good frequency response, allows it to be employed in both analog and digital circuits.

Encased in the TO-92 plastic package, the BC327 transistor provides excellent reliability at a low cost. It features a maximum collector-emitter voltage (Vce) of -45V, making it suitable for circuits with relatively higher voltage requirements compared to general small-signal transistors. The BC327 also comes in gain groupings (A, B, C), providing flexibility in selecting the right variant with DC gain (hFE) between 100 and 630.

BC327 PNP Transistor

The transistor is highly popular in audio amplifier stages, switching regulators, signal processing units, and microcontroller interface circuits. It offers stable performance, low saturation voltage, and the ability to deliver moderate current, which makes it useful in both educational projects and professional designs. Because of its versatility and robust design, the BC327 remains one of the go-to PNP transistors for hobbyists, students, and engineers alike.

BC327 Pinout

BC327 Transistor Key Features

• PNP transistor designed for low and medium power applications.
• Can drive relatively higher current loads compared to small-signal transistors.
• Available in multiple gain groupings (A, B, C).
• Compact and cost-effective TO-92 package.
• Reliable choice for audio, switching, and general-purpose circuits.
• Long-term availability and proven performance in industry and DIY projects.

Specifications/Characteristics of BC327 PNP Transistor

• Maximum Collector-Base Voltage (Vcb): -50V
• Maximum Collector-Emitter Voltage (Vce): -45V
• Maximum Emitter-Base Voltage (Veb): -5V
• Maximum Collector Current (Ic): -800mA
• Total Power Dissipation (Ptot): 625mW
• DC Current Gain (hFE): 100 – 630 (depending on variant A, B, or C)
• Transition Frequency (ft): 100 MHz (typical)
• Junction Temperature Range: -65°C to +150°C
• Package: TO-92 plastic

BC327 Pin Configuration

More Circuit Layouts

Key Applications of BC327 PNP Transistor

• Audio frequency amplification.
• Switching of relays, LEDs, and small loads.
• General-purpose low to medium power amplification.
• Microcontroller and sensor interface circuits.
• Motor driver and regulator circuits.
• Signal processing and waveform generation.

NPN Complimentary Transistor

BC337 (NPN) is the complementary transistor to BC327.

Equivalent Transistors of BC327

• BC328 (PNP, higher current handling).
• BC557 (PNP, small-signal general purpose).
• BC558 (PNP, low-noise audio applications).
• 2N3906 (PNP, general-purpose transistor).
• 2N2907 (PNP, higher current applications).

(Pin configuration of some transistors mentioned here may different from BC327).

Datasheet of BC327 PNP Transistor

Click the following Button below to download the datasheet of BC327 Transistor :
