Introduction

In the world of electronics, power amplifiers play a crucial role in delivering high-quality audio signals with sufficient power to drive speakers. One such power amplifier circuit is the 100W PNP Power Amplifier Circuit Diagram, which can be built at home using a pair of TIP36, BD139, BD140, and BC556 transistors. This DIY project enables audio enthusiasts to construct their own powerful amplifier and enjoy an immersive audio experience. In this article, we will discuss the circuit diagram, its specifications, and the step-by-step process of building this amplifier.

The 100W PNP Power Amplifier Circuit utilizes a simple yet effective configuration of electronic components. At its core are the TIP36 power transistors that deliver a clean, powerful output. Here is the specification of this transistor:

TIP36 Transistor Specification:

The TIP36 transistor is a versatile and reliable PNP power transistor. It is specifically designed for high-power audio amplifier applications. With a maximum collector current of 25A and a collector-emitter voltage of 100V, the TIP36 can handle high power levels without any compromise in performance. Its high current gain and low saturation voltage make it an ideal choice for constructing power amplifiers.



100W PNP Amplifier Circuit Diagram

This project can be built using a few basic components. The circuit diagram of this project is shown below.

100W PNP Power Amplifier Circuit Diagram
100W PNP Power Amplifier Circuit Diagram
35V power supply Circuit Diagram
35V power supply Circuit Diagram




More Circuit Layouts





Components List of 100W PNP Amplifier Circuit Diagram

Following is the list of all components used in this project:

  • TIP36 Transistor x 2
  • BD139 Transistor x 2
  • BD140 Transistor x 1
  • BC556AP Transistor x 2
  • 1k Resister x 2
  • 22k Resister x 2
  • 18k Resister x 1
  • 560R Resister x 1
  • 100R Resister x 1
  • 2K7 Resister x 2
  • 1uF Capacitor x 1
  • 100pF Capacitor x 1
  • 100uF Capacitor x 1
  • 47pF Capacitor x 1
  • 47uF Capacitor x 1
  • 1N4007 Diode x 4
  • +/-35V Power Supply




Conclusion of 100W PNP Amplifier Circuit

Building a PNP Power Amplifier Circuit at home not only allows DIY enthusiasts to showcase their skills but also offers a gratifying audio experience. By utilizing a pair of TIP36, BD139, BD140, and BC556 transistors, this circuit can deliver powerful audio signals without compromising on quality. The TIP36 transistor’s specifications make it an excellent choice for constructing high-power amplifiers. So, if you’re a passionate audio enthusiast looking for a DIY project, this amplifier circuit will undoubtedly provide an immersive listening experience that will keep you entertained for hours. Happy building!

More projects, You may like:



For more project and circuit diagrams, you can go through the Schematics in the main menu where you can find many interesting projects and circuit diagrams like audio amplifier circuits, voltage booster circuitbattery charger circuit and timer circuits etc., which are all beginner circuit projects. Feel free to check them out!
